Special Polypropylene Biaxial Geogrid For Soil Erosion Prevention

Special Polypropylene Biaxial Geogrid For Soil Erosion Prevention
Features Gallery Product Description Request A Quote
Features
Specifications
Application: Landfill/Reinforcement/Drainage
Color: Black
Material: Polypropylene
Width: 4m~5m
Unit Weight: 300±30~600±30g/㎡
Tensile Strength(LD): 15~50KN/m
Tensile Strength(TD): 15~50KN/m
Tensile Strength At 2% Elongation: 5~17.5KN/m
Highlight:

Special Polypropylene Biaxial Geogrid

,

Erosion Prevention Polypropylene Biaxial Geogrid

,

Soil Erosion Prevention PP Biaxial Geogrid

Basic Infomation
Place of Origin: China
Brand Name: JianYi
Certification: ISO9001
Payment & Shipping Terms
Product Description

Special Biaxial Plastic Geogrid For Soil Erosion Prevention



Product Introduction



    Bidirectional plastic geoglage is an important geosynthetic material, which can increase the bearing capacity of the foundation and prolong the service life of the foundation during use.



Product Property



1. Increase the bearing capacity of the road (ground) foundation and extend the service life of the road (ground) foundation
2. Prevent road (ground) surface collapse or crack, keep the ground beautiful and neat
3. Convenient construction, time saving, labor saving, shorten the construction period, reduce maintenance costs
4. Prevent cracks in culverts
5. Strengthen soil slope to prevent soil erosion
6. Reduce cushion thickness and save cost
7. Support the stability of the slope planting mat green environment



Product Application



1. Subgrade reinforcement: increase the bearing capacity of subgrade, prolong the service life of subgrade.
2. Ground beautification: prevent the ground collapse or crack, keep the ground beautiful and neat.
3. Culvert protection: prevent cracks in culverts.
4. Slope reinforcement: strengthen the soil slope to prevent soil erosion.
5. Green environment: stable green environment of supporting slope planting mat.
6. Aquaculture: Used for animal husbandry nets, cage fish nets.
7. Mine reinforcement: Used for mine and tunnel reinforcement.



Product Specification and Technical Index



Specification Item TGSG15-15 TGSG20-20 TGSG25-25 TGSG30-30 TGSG35-35 TGSG40-40 TGSG45-45 TGSG50-50
Unit Weight (g/m2) 300 ± 30 330 ± 30 380 ± 30 400 ± 30 450 ± 30 500 ± 30 550 ± 30 600 ± 30
Width (m) 4.0 5.0 4.0 5.0 4.0 5.0 4.0 5.0 4.0 5.0 4.0 5.0 4.0 5.0 4.0 5.0
Tensile Strength (KN/m≥, LD) 15 20 25 30 35 40 45 50
Tensile Strength (KN/m≥, TD) 15 20 25 30 35 40 45 50
Yield Elongation (%≤, LD) 13 13 13 13 13 13 13 13
Yield Elongation (%≤, TD) 16 16 16 16 16 16 16 16
Tensile Strength at 2% Elongation (KN/m≥, LD) 5 7 9 10.5 12 14 16 17.5
Tensile Strength at 2% Elongation (KN/m≥, TD) 5 7 9 10.5 12 14 16 17.5
Tensile Strength at 5% Elongation (KN/m≥, LD) 7 14 17 21 24 28 32 35
Tensile Strength at 5% Elongation (KN/m≥, TD) 7 14 17 21 24 28 32 35
