High-Performance Geotextile Woven Fabric for Superior Ground Stabilization

Woven geotextile is a kind of geosynthetic material woven from high polymer materials such as polyethylene and polypropylene. It has very good mechanical properties, weather resistance, corrosion resistance and water permeability. It has a compact structure and high tensile strength, and can withstand the pressure of soil and garbage to maintain the stability of the structure. It also has good weather resistance and corrosion resistance, so it can be used for a long time in various harsh environments and is not easy to age or break. It also has very good water permeability, which can remove excess moisture from the soil and garbage to keep the structure dry and stable.

Key Features:

Exceptional Tensile Strength: Withstands heavy loads and high-stress conditions, making it ideal for road construction, embankment reinforcement, and slope stabilization.

Superior Puncture Resistance: Protects against sharp objects and abrasions, ensuring long-term performance in demanding environments.

Excellent Filtration and Drainage: Promotes efficient water flow while preventing soil erosion, maintaining structural integrity in drainage systems and retaining walls.

UV and Chemical Resistance: Designed to endure harsh weather conditions and resist degradation from chemicals, ensuring reliable performance in outdoor applications.

Customizable Sizes and Weights: Available in various widths, lengths, and weights to meet the specific requirements of your project.

• Product Series	Unit	Tolerance	Geotextile Mattress Fabric
  			ZXM-120-200	ZXM250-500	ZXM550
  Mass per Unit Area (Single)	g/m²	-3%	240	280	380
  Tensile Strength (Longitudinal)	N/5cm	≥	2500	3000	3800
  Elongation (Longitudinal)	%	≤	30	30	30
  Tensile Strength (Transverse)	N/5cm	≥	2300	2800	3100
  Elongation (Transverse)	%	≤	28	28	28
  CBR Bursting Strength	N	≥	4000	5000	6000
  Vertical Permeability Coefficient	cm/s	≥	1.3×10⁻²	1.5×10⁻²	1.8×10⁻²
  Equivalent Aperture O95	mm	≤	0.18	0.22	0.25

Applications:

1.Road and railway construction

2.Landfill and erosion control

3.Retaining walls and embankments

4.Drainage systems and coastal protection

5.Agriculture and landscaping projects

Choose our geotextile woven fabric for a reliable, cost-effective solution that enhances the stability and longevity of your construction projects. Trust in our expertise to provide the highest quality materials for your ground stabilization needs. Contact us today to learn more or request a sample!
