The Sodium Bentonite Waterproof Blanket is a highly effective, eco-friendly waterproofing solution designed for a wide range of construction and environmental applications. Composed of natural sodium bentonite clay sandwiched between geotextile layers, this waterproof blanket offers superior self-sealing properties, durability, and ease of installation. It is an ideal choice for projects requiring reliable and long-lasting waterproofing, such as landfills, ponds, tunnels, and foundations.
Key Features:
Self-Sealing Properties:
Sodium bentonite clay swells upon contact with water, forming a dense, impermeable barrier.
Automatically seals cracks and gaps, ensuring continuous waterproofing.
Natural and Eco-Friendly:
Made from 100% natural sodium bentonite, a non-toxic and environmentally safe material.
Free from harmful chemicals, making it suitable for potable water applications.
High Durability:
Resistant to punctures, tears, and UV degradation.
Withstands harsh environmental conditions, including freeze-thaw cycles.
Easy Installation:
Lightweight and flexible, allowing for quick and straightforward deployment.
Can be easily cut and shaped to fit complex geometries.
Cost-Effective:
Reduces the need for additional waterproofing materials and labor.
Provides long-term performance with minimal maintenance.
Versatile Applications:
Suitable for a wide range of waterproofing and containment projects.
Compatible with various substrates, including concrete, soil, and geosynthetics.
Applications:
Civil Engineering:
Tunnel and subway waterproofing
Foundation and basement waterproofing
Retaining wall barriers
Environmental Protection:
Landfill liners and caps
Pond and lagoon liners
Secondary containment for hazardous materials
Water Management:
Reservoirs and irrigation canals
Stormwater management systems
Potable water storage
Mining and Industrial:
Tailings storage facilities
Heap leach pads
Chemical containment
Technical Specifications:
Material: Natural sodium bentonite clay with geotextile layers
Bentonite Weight: 4.0 kg/m² to 6.0 kg/m² (customizable)
Thickness: 5 mm to 7 mm (depending on bentonite weight)
Width: Up to 5 meters (standard)
Length: Custom rolls available
Color: Typically geotextile layers
Technical Index (JG/T 193-2006)
| ITEM |
GCL-NP
(Needle Puched Process GCL) |
GCL-OF
(Needle Puched and Cocoon Process GCL) |
GCL-AH
(Viscose Process GCL) |
| Unit Weight (g/㎡) |
≥4000
Not less than the specified value |
≥4000
Not less than the specified value |
≥4000
Not less than the specified value |
| Bentonite Swell Index (ml/2g) |
≥24 |
≥24 |
≥24 |
| Blue Clay (g/100g) |
≥30 |
≥30 |
≥30 |
| Tensile Strength (N/mm) |
≥600 |
≥700 |
≥600 |
| Elongatio At Max Load (%) |
≥10 |
≥10 |
≥8 |
Peel Strength
(N/100mm) |
No-woven Geotextile&
Woven Geotextile |
≥40 |
≥40 |
- |
PE Geomembrane &
No-woven Geotextile |
- |
≥30 |
- |
| Pesistance Hydraulic Pressure (m/s) |
≤5.0X10ˉ11 |
≤5.0X10ˉ12 |
≤1.0X10ˉ12 |
| Resistance Hydraulic Pressure |
0.4MPa,1h,No Leakage |
0.6MPa,1h,No Leakage |
0.6MPa,1h,No Leakage |
| Fluid Loss (m/L) |
≤18 |
≤18 |
≤18 |
| Durability Of Bentonite (mL/2g) |
≥20 |
≥20 |
≥20 |
Why Choose Our Sodium Bentonite Waterproof Blanket?
Proven Performance: Trusted by engineers and contractors worldwide for its reliability and effectiveness.
Custom Solutions: Available in various sizes and configurations to meet specific project requirements.
Expert Support: Our team provides technical assistance and installation guidance.
Sustainable Choice: Made from natural materials, contributing to environmentally responsible construction practices.
Ordering Information:
Contact our sales team today to request a quote or discuss your project needs. We offer flexible shipping options and timely delivery to ensure your project stays on schedule.
