Excellent Filtration and Drainage Black Polypropylene Woven Geotextile

Woven Geotextiles could be used in rock projects such as highways, railways, airports, rock dams, breakwaters, retaining walls, backfills, borders, etc., to disperse soil stress, increase soil modulus, limit soil slip, and improve stability.

Key Features:

Exceptional Tensile Strength: Withstands heavy loads and high-stress conditions, making it ideal for road construction, embankment reinforcement, and slope stabilization.

Superior Puncture Resistance: Protects against sharp objects and abrasions, ensuring long-term performance in demanding environments.

Excellent Filtration and Drainage: Promotes efficient water flow while preventing soil erosion, maintaining structural integrity in drainage systems and retaining walls.

UV and Chemical Resistance: Designed to endure harsh weather conditions and resist degradation from chemicals, ensuring reliable performance in outdoor applications.

Customizable Sizes and Weights: Available in various widths, lengths, and weights to meet the specific requirements of your project.

• Product Series	Unit	Tolerance	Geotextile Mattress Fabric
  			ZXM-120-200	ZXM250-500	ZXM550
  Mass per Unit Area (Single)	g/m²	-3%	240	280	380
  Tensile Strength (Longitudinal)	N/5cm	≥	2500	3000	3800
  Elongation (Longitudinal)	%	≤	30	30	30
  Tensile Strength (Transverse)	N/5cm	≥	2300	2800	3100
  Elongation (Transverse)	%	≤	28	28	28
  CBR Bursting Strength	N	≥	4000	5000	6000
  Vertical Permeability Coefficient	cm/s	≥	1.3×10⁻²	1.5×10⁻²	1.8×10⁻²
  Equivalent Aperture O95	mm	≤	0.18	0.22	0.25

Applications:

Woven polypropylene monofilament geotextiles are produced from tapes (tape fabrics) or yarns. A fabric consists of warp yarns and weft yarns. The fabrics are made of polypropylene monofilament and tape yarns which provide excellent hydraulic and physical properties.

The main functions of plastic tape woven geotextile:

• Reinforcement woven geotextile: In order to stabilize the containment of the works that occurs during long-term use, the well can pass the stress acting locally or dispatched to the ground over a larger area
• Separation woven geotextile: Geotextiles of different geotextile material structures are separated to form a stable interface, according to the requirements and the respective characteristics play an integral role.
• Drainage and Filtration Woven Geotextile: The working cloth can allow water to pass through and block the loss of sand particles. When used for drainage, place the geotextile on the soil with poor water permeability to slowly pump the water well and move the water along the working cloth. The purpose of quickly expelling

Applications of woven geotextile

• Water conservancy engineering: compliance engineering of seawalls, river embankments, river banks and lake embankments; bottom protection engineering, water diversion and irrigation engineering; hazard prevention and elimination engineering and seepage reinforcement of reservoirs; reclamation engineering; flood prevention engineering.
• Highway engineering: soft base treatment; slope protection; pavement structure layer; anti-reflective seam; drainage system; green belt;
• Railway project: railway subgrade strengthening works; embankment slope reinforcement layers; waterproof tunnel lining, drainage layer; geotextile blind drainage ditch
• Airport projects: runway foundation reinforcement; base and apron pavement layer; airport road and drainage system;
• Power plant: basic engineering of nuclear power plants; thermal power plant ash dam project; Hydroelectric project.

Choose our geotextile woven fabric for a reliable, cost-effective solution that enhances the stability and longevity of your construction projects. Trust in our expertise to provide the highest quality materials for your ground stabilization needs. Contact us today to learn more or request a sample!
