Self-healing Environmentally Friendly Bentonite Waterproof Blanket with Low Construction Cost for Geosynthetic Clay Liner Applications

180㎡
MOQ
0.83USD~2.75USD per sqm
Price
Self-healing Environmentally Friendly Bentonite Waterproof Blanket with Low Construction Cost for Geosynthetic Clay Liner Applications
Features Gallery Product Description Request A Quote
Features
Specifications
Width: 4-6m
Swelling Index: ≥24ml/2g
Type: Geosynthetic Clay Liner
Unit Weight: ≥4000g/㎡
Blue Clay: ≥30g/100g
Elongatio At Max Load: ≥10%
Pesistance Hydraulic Pressure: ≤5.0X10ˉ11m/s
Durability Of Bentonite: ≥20mL/2g
Highlight:

Self-healing Bentonite Waterproof Blanket

,

Environmentally Friendly Geosynthetic Clay Liner

,

Low Construction Cost Bentonite GCL
Basic Infomation
Place of Origin: China
Brand Name: JianYi
Certification: ISO 9001 CE
Model Number: 4000-6000g/㎡
Payment & Shipping Terms
Delivery Time: 30 days
Payment Terms: T/T,L/C
Supply Ability: 3000T/month
Product Description
Bentonite Waterproof Blanket - Environmental Protection Oriented Anti-seepage Material
Product Introduction
Our environmentally friendly bentonite waterproof blanket is manufactured using 100% natural sodium bentonite and biodegradable geotextile materials. This innovative product eliminates the need for chemical adhesives and harmful additives, ensuring zero environmental pollution throughout its lifecycle—from production and application to disposal. The waterproofing mechanism relies on bentonite's natural water-swelling properties, providing a sustainable and eco-conscious waterproofing solution.
Product Features
  • Green and Environmentally Friendly: Composed of natural, biodegradable materials with no harmful substances, compliant with global environmental standards
  • Self-Healing Performance: Automatically repairs minor damage to the waterproof layer through bentonite swelling, restoring impermeable integrity
  • Excellent Compatibility: Compatible with various environmental media, no chemical reactions with soil or water, ensuring environmental stability
  • Cost-Effective Installation: Simple construction process requiring no specialized equipment, reducing labor costs and project timelines
Application Fields
This bentonite waterproof blanket is extensively used in ecological restoration projects including wetland protection and river regulation, drinking water source protection initiatives, agricultural irrigation channels, green building basement waterproofing, and organic waste treatment facilities. It serves as the preferred solution for projects with stringent environmental protection requirements.
Product Installation Guidelines
  • Base Surface Preparation: Thoroughly clean the substrate, removing weeds, stones, and debris. Ensure the surface is dry and level
  • Laying Procedure: Lay the BWB flat on the prepared surface without excessive tension. Allow sufficient slack to accommodate substrate movement. Manually compact overlaps to ensure tight contact
  • Fixing Requirements: Secure using wooden stakes or plastic fixing nails arranged in a grid pattern with 1.5-2m spacing. Avoid metal components that may corrode
  • Post-Construction Protection: Protect from prolonged direct sunlight. Cover laid BWB with waterproof cloth during construction interruptions. Complete backfilling promptly after project completion
Environmental Advantage: This product represents a sustainable waterproofing solution that aligns with modern environmental protection standards while delivering reliable performance across diverse applications.
