Home /Products/HDPE Smooth Geomembrane/Anti Seepage HDPE Geomembrane Sheets 0.3mm-3.0mm For Mining

Anti Seepage HDPE Geomembrane Sheets 0.3mm-3.0mm For Mining

325㎡
MOQ
0.41USD~5.5USD per sqm
Price
Anti Seepage HDPE Geomembrane Sheets 0.3mm-3.0mm For Mining
Features Gallery Product Description Request A Quote
Features
Specifications
Color: Black, Green, Custom
Material: High Density Polyethylene (HDPE)
Thickness: 0.3mm-3.0mm
Length: 30m-100m
Width: 1m-9m
Application: Landfill, Mining, Pond Liner, Etc.
Temperature Resistance: -60℃ To +60℃
Elongation At Break: ≥600%
Highlight:

Anti Seepage HDPE Geomembrane Sheets

,

Mining HDPE Geomembrane Sheets

,

3mm HDPE Geomembrane Sheets
Basic Infomation
Place of Origin: China
Brand Name: JianYi
Certification: ISO 9001
Model Number: 1m-9m Width and 30m-100m Roll Length
Payment & Shipping Terms
Delivery Time: 7-15 days
Payment Terms: T/T, L/C
Supply Ability: 1300T/Month
Product Description

Versatile HDPE Geomembrane For Various Anti-Seepage Projects



Product Introduction

    HDPE membrane, full name high-density polyethylene membrane, also known as HDPE geomembrane or HDPE impervious membrane, is a plastic rolled material made of high-density polyethylene (HDPE) resin. HDPE membrane has various excellent properties, which make it widely used in engineering waterproofing field.



Product Properties

♦  Excellent chemical resistance (corrosion resistance);

♦  Outstanding stress cracking resistance (environmental stress cracking resistance);

♦  Lowest permeability;

♦  Excellent UV resistance;

♦  Stable resistance to low temperature embrittlement;



Product Application

    HDPE geomembrane is widely used in many fields due to its unique properties. In terms of municipal environmental protection, it can be used for anti-seepage projects such as domestic waste landfill anti-seepage, solid waste landfill anti-seepage, sewage treatment plant anti-seepage, artificial lake anti-seepage, and tailings treatment. In water conservancy anti-seepage projects, HDPE geomembrane can meet the anti-seepage treatment needs of dams and drainage ditches, as well as anti-pollution treatment of waste sites. In addition, it is also suitable for anti-seepage projects of transportation infrastructure, agricultural water conservancy anti-seepage projects, aquaculture industry, and other construction anti-seepage, anti-corrosion, anti-leakage, reinforcement, collection of leachate, and prefabrication of special components of temporary container structures.



Product Specification

* Thickness(mm): 0.30mm~3.00mm
* Width:1m~9m
* Roll length: 30m~100m (customized request accept)
PS: Customized request accept for all above.



Geomembrane Series
Smooth HDPE Geomembrane For Landfill (GH-2S & GB/T 17643-2011)

Specification 0.75mm 1.00mm 1.25mm 1.50mm 2.00mm 2.50mm 3.00mm Remark
Item
Thickness (mm) 0.75mm 1.00mm 1.25mm 1.50mm 2.00mm 2.50mm 3.00mm
Density (g/c㎡,≥) 0.939
Tensile Properties
Yield Strength (N/mm,LD/TD) 11 15 18 22 29 37 44
Breaking Strength (N/mm,LD/TD) 20 27 33 40 53 67 80
Yeild Elongation Rate (%) 12
Breaking Elongation Rate (%) 700
Rectangular Tear Strength (N) 93 125 156 187 249 311 374
Puncture Strength (N) 240 320 400 480 640 800 960
Environmental Stress Crack Resistance (h)
(A single point of incision constant tensile method)		 300
Carbon Black
Carbon Black Content(Rang) (%) 2.0~3.0
Carbon Black Dispersion Nine of 10 observation area should be grade 1 or grade 2, not more than 1 of grade3
Oxidative Induction Time (OIT)
Standard OIT (min) 100
High Pressure OIT (min) 400
85℃ Oven Ageing (Minimum Average)
90 days after baking, the standard OIT retention(%) 55
90 days after baking, the hight pressure OIT retention(%) 80
The Anti-UV Strength
Ultraviolet irradiation after 1600 hours, the standard OIT retention(%) 50
Ultraviolet irradiation after 1600 hours, the high pressure OIT retention(%) 50
-70℃ The Low Temperature Embrittlement Performance mpact Pass
Water Vapor Penetration Coefficient g.cm (cm2.s.Pa) ≤1.0X10-13
Dimensional Stability ±2



Product Specification and Technical Index (GH-1 & GB/T 17643-2011)

Specification
Item		 0.30 0.50 0.75 1.00 1.25 1.50 2.00 2.50 3.00 Remark
Thickness (mm) 0.30 0.50 0.75 1.00 1.25 1.50 2.00 2.50 3.00
Density (g/c㎡,≥) 0.94
Tensile Yield Strength (N/mm, ≥,LD/TD) 4 7 10 13 16 20 26 33 40
Tensile Breaking Strength (N/mm, ≥,LD/TD) 6 10 15 20 25 30 40 50 60
Yield Elongation Rate (%,≥,LD/TD) - - - 11
Breaking Elongation Rate (%,≥,LD/TD) 600
Rectangular Tear Load (N,≥,LD/TD) 34 56 84 115 140 170 225 280 340
Puncture Strength (N,≥) 72 120 180 240 300 360 480 600 720
Carbon Black Content (%) 2.0~3.0
Carbon Black Dispersion Less than 1date of Grade 3 out of 10 data, grade 4,grade 5 is not allowed
