Name: Customizable HDPE Textured Geomembrane for Industrial and Mining Applications
Brand: Hebei Bending Fence Technology Co., Ltd.
SKU: 6m-8m Width and 50m-100m Roll Length
Price: 3.38 USD
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Puncture Resistance: 267-534N

Yeild Elongation Rate: 12%

Breaking Elongation: 100%

Length: 50m-100m

Width: 4m-8m

Surface: Roughened

Thickness: 0.5~2.5mm

Material: HDPE

Application: Landfill, Mining, Pond Liner, Etc.

Color: Black

Highlight:

Customizable HDPE Textured Geomembrane

Mining HDPE Textured Geomembrane

Industrial HDPE Textured Geomembrane

Basic Infomation

Place of Origin: China

Brand Name: JianYi

Certification: ISO9001

Model Number: 6m-8m Width and 50m-100m Roll Length

Payment & Shipping Terms

Delivery Time: 7-15 days

Payment Terms: T/T, L/C

Supply Ability: 1200t/month

Gallery

Customizable HDPE Textured Geomembrane for Industrial and Mining Applications

Product Description

Customizable HDPE Textured Geomembrane for Industrial and Mining Applications

Product Introduction

Column point geomembrane is a type of impermeable material made from high molecular polymer as the basic raw material. It not only prevents liquid seepage but also prevents gas volatilization. This material has a wide range of applications in construction engineering, highway tunnels, subways, railway tunnels, industrial and mining, and municipal underground engineering projects.

Product Properties

The characteristics of the pillar point geomembrane lie in its surface pillar point structure, which is formed by a special mold pressing roller, evenly distributed, both beautiful and capable of increasing the friction coefficient. The front and back sides of the membrane can be hot-fused into one with different materials and colors, allowing the product's front and back sides to be set according to geological conditions and engineering requirements in engineering applications. This production process not only retains the mechanical properties of the material itself, as well as good elongation and chemical property stability, but also enhances the product's tensile, wear resistance, and puncture resistance through the addition of a certain proportion of functional additives. In addition, the pillar point geomembrane has a high resistance to acid and alkali, microbial, and chemical erosion.

Product Application

The column point geomembrane not only has the function of imperviousness and pollution prevention in engineering laying, but also has the function of anti-skid, which is especially suitable for the application of engineering slope surface, and is convenient for strengthening the adhesion degree in the secondary laying of geotechnical fabric, with the advantage of convenient construction. It is an ideal material for landfill site imperviousness and pollution prevention projects. In addition, the column point geomembrane is also widely used in the seepage prevention of the reservoir basin and the seepage plugging and leakage prevention of the dike, canal seepage prevention, water diversion tunnel seepage prevention, slope protection and other fields.

In summary, column point geomembrane is a versatile impermeable material. Its unique design and superior performance make it play an important role in various engineering fields.

Geomembrane Series

Textured HDPE Geomembrane For Landfill (GB/T 17643-2011(GH-2T1,GH-2T2))

Serial Number	Project	Index
Serial Number	Thickness(mm)	0.75	1.00	1.25	1.50	2.00	2.50	3.00
1	Density (g/c㎡,≥)	≥0.940
2	Textured Highth (mm)	≥0.25
3	Yield Strength (N/mm,LD/TD)	≥11	≥15	≥18	≥22	≥29	≥37	≥44
4	Breaking Strength (N/mm,LD/TD)	≥8	≥10	≥13	≥16	≥21	≥26	≥32
5	Yeild Elongation Rate (%)	≥12
6	Breaking Elongation Rate (%)	≥100
7	Rectangular Tear Strength (N)	≥93	≥125	≥160	≥190	≥250	≥315	≥375
8	Puncture Strength (N)	≥200	≥270	≥335	≥400	≥535	≥670	≥800
9	Tensile Load Stress Cracking (Notch Constant Load Tensle Method) h	≥300
10	Carbon Black Content(Rang) (%)	2.0~3.0
11	Carbon Black Dispersion	There is not more than one grade 3 in 10 data, and grade 4 and grade 5 are not allowed
12	Oxidative Induction Time (OIT)	Standard OIT (min)≥100
12	Oxidative Induction Time (OIT)	High Pressure OIT (min)≥400
13	85℃ thermal aging (Atmospheric Pressure OIT Retention After 90 Day)	≥55
14	Ultraviolet Irradiation After 1600 Hours, The OIT Retention(%)	≥50

(CJ-T234-2006)

Specification	1.00mm	1.25mm	1.50mm	2.00mm	2.50mm	3.00mm	Remark
Item
Thickness (mm)	1.00mm	1.25mm	1.50mm	2.00mm	2.50mm	3.00mm
Textured Highth (mm)	0.25
Density (g/c㎡,≥)	0.94
Tensile Properties
Yield Strength (N/mm,LD/TD)	15	18	22	29	37	44
Breaking Strength (N/mm,LD/TD)	10	13	16	21	26	32
Yeild Elongation Rate (%)	12
Breaking Elongation Rate (%)	100
Rectangular Tear Strength (N)	125	156	187	249	311	374
Puncture Strength (N)	267	333	400	534	667	800
Environmental Stress Crack Resistance (h) (A single point of incision constant tensile method)	300
Carbon Black
Carbon Black Content(Rang) (%)	2.0~3.0
Carbon Black Dispersion	Nine of 10 observation area should be grade 1 or grade 2, not more than 1 of grade3
Oxidative Induction Time (OIT)
Standard OIT (min)	100
High Pressure OIT (min)	400
85℃ Oven Ageing (Minimum Average)
90 days after baking, the standard OIT retention(%)	55
90 days after baking, the hight pressure OIT retention(%)	80
The Anti-UV Strength
Ultraviolet irradiation after 1600 hours, the standard OIT retention(%)	50
Ultraviolet irradiation after 1600 hours, the high pressure OIT retention(%)	50
-70℃ The Low Temperature Embrittlement Performance mpact	Pass
Water Vapor Penetration Coefficient g.cm (cm2.s.Pa)	≤1.0X10-13
Dimensional Stability	±2
