Textured HDPE Geomembrane for Mine Slope Anti-Seepage with Enhanced Anti-Slip Performance and Excellent UV Resistance

Textured HDPE Geomembrane for Mine Slope Anti-Seepage with Enhanced Anti-Slip Performance and Excellent UV Resistance
Features Gallery Product Description Request A Quote
Features
Specifications
Material: High Density Polyethylene (HDPE)
Color: Black, Green, Custom
Temperature Range: -70°C To 80°C
Thickness: 0.3mm-3.0mm
Elongation At Break: 700%
Density: 0.939g/cm3
Uv Resistance: Excellent
Width: 1m-9m
Chemical Resistance: Excellent
Length: 30m-100m
Puncture Strength: 240-960N
Application: Landfill,dam
Type: Geomembranes
Highlight:

Mine Slope Anti-Seepage Textured HDPE Geomembrane

,

Enhanced Anti-Slip Performance HDPE Geomembrane

,

Excellent UV Resistance Geomembrane
Basic Infomation
Place of Origin: China
Brand Name: JianYi
Certification: ISO9001
Payment & Shipping Terms
Product Description
Textured HDPE Geomembrane for Mine Slope Anti-Seepage
The Textured HDPE Geomembrane is a specialized anti-seepage material engineered for slope applications in mining areas. Manufactured from premium HDPE resin with UV stabilizers and anti-aging additives, this product features a rough textured surface on one or both sides to significantly increase friction coefficients and prevent slippage on steep slopes.
Product Specifications
Thickness Range: 0.8mm to 3.0mm
Surface Roughness: Ra ≥3.0μm
Friction Coefficient: ≥0.5
Permeability Coefficient: ≤1.0×10⁻¹³ cm/s
Temperature Resistance: -60℃ to 80℃
Maximum Slope Ratio: 1:1.2
Key Features & Benefits
  • Enhanced Anti-Slip Performance: Textured surface increases friction coefficient to prevent geomembrane slippage on steep slopes, ensuring system integrity
  • Reliable Anti-Seepage Protection: Ultra-low permeability coefficient effectively isolates mining chemicals and prevents soil and groundwater contamination
  • Superior Weather Resistance: Withstands extreme temperatures and prolonged UV radiation, adapting to harsh mining area conditions
  • Excellent Weldability & Mechanical Strength: Ensures easy installation and provides long-term service life in demanding environments
Application Scenarios
This geomembrane is specifically designed for slope anti-seepage applications in mining operations, including:
  • Mine tailings dam slopes
  • Waste rock dump slopes
  • Open-pit mine pit slopes
  • Leachate pond slopes
  • Slope-type wastewater storage ponds
  • Slope-type chemical storage ditches
Suitable for various mine types including metal mines, coal mines, and non-metallic mines, particularly where anti-slip performance is critical on steep slopes.
Installation Guidelines
  • Position textured surface upward (contact with slope soil) to maximize friction; for containment structures, face textured surface toward soil or filler
  • Ensure slope surface is flat and free of sharp objects before installation
  • Lay geomembrane from bottom to top with 15-20cm overlaps between adjacent membranes
  • Use HDPE welding machine for seams; employ special welding nozzle for textured surfaces
  • Secure top and bottom with anchor grooves or anchor bolts to prevent displacement
  • Conduct comprehensive leak testing (air pressure or water filling test) post-installation
  • Avoid dragging heavy objects across geomembrane surface to protect textured layer
