Black and Green Dual-color HDPE Smooth Geomembrane Suitable for Various Waterproof Projects

Black and Green Dual-color HDPE Smooth Geomembrane Suitable for Various Waterproof Projects
Features Gallery Product Description Request A Quote
Features
Specifications
Puncture Resistance: 240-960N
Chemical Resistance: Excellent
Tear Strength: 93-374N
Usage: Liners
Color: Black, Green, Custom
Carbon Black Content: 2.0%-3.0%
Material: High Density Polyethylene (HDPE)
Application: Landfill, Mining, Water Containment, Etc.
Width: 1m-9m
Elongation At Break: 700%
Thickness: 0.3mm-3.0mm
Highlight:

Waterproof HDPE Smooth Geomembrane

,

Green HDPE Smooth Geomembrane

,

Black HDPE Smooth Geomembrane
Basic Infomation
Place of Origin: China
Brand Name: JianYi
Certification: ISO9001
Payment & Shipping Terms
Product Description

Black and Green Dual-color HDPE Smooth Geomembrane Suitable for Various Waterproof Projects



Product Introduction

The black and green dual-color HDPE geomembrane is a high-density polyethylene (HDPE) or low-density polyethylene (LLDPE) material formed through double-layer co-extrusion blow molding. It is characterized by its two sides, one black and the other green. This design gives it a wide range of applications in various fields.



Product Properties

1. Environmental protection: does not contain harmful substances, do not pollute the environment.
2. Reusability: Only the surface layer can be replaced, saving resources.
3. Wide range of application: suitable for basement, pool and other types of waterproof projects.
4. Uv resistance: Protects the material from UV damage.
5. Good stability: it is not easy to deform or break under physical action.



Product Application

  • Landfill Cover: The green side is up, mainly for aesthetic and environmental purposes. It also has anti-aging and light stability properties, with a lifespan of more than five years.

  • Slope Covering: Prevents rainwater from seeping into the landfill, increasing its service life and reducing the cost of leachate treatment.

  • Tailings Pond Covering: Utilizing the aesthetic and environmental benefits of the green side, while the black side faces down to effectively prevent moisture penetration.

The black and green dual-color HDPE geomembrane has been widely used in multiple engineering projects, including but not limited to canal renovation, artificial lakes, water conservancy construction projects, etc. In particular, its excellent impermeability and convenient construction have been widely recognized in channel seepage prevention projects.



Product Specification

*  Thickness(mm): 0.30mm~3.00mm
*  Width:1m~9m
*  Roll length: 30m~100m (customized request accept)
PS: Customized request accept for all above.



Geomembrane Series
Smooth HDPE Geomembrane For Landfill (GH-2S & GB/T 17643-2011)

Specification 0.75mm 1.00mm 1.25mm 1.50mm 2.00mm 2.50mm 3.00mm Remark
Item
Thickness (mm) 0.75mm 1.00mm 1.25mm 1.50mm 2.00mm 2.50mm 3.00mm
Density (g/c㎡,≥) 0.939
Tensile Properties
Yield Strength (N/mm,LD/TD) 11 15 18 22 29 37 44
Breaking Strength (N/mm,LD/TD) 20 27 33 40 53 67 80
Yeild Elongation Rate (%) 12
Breaking Elongation Rate (%) 700
Rectangular Tear Strength (N) 93 125 156 187 249 311 374
Puncture Strength (N) 240 320 400 480 640 800 960
Environmental Stress Crack Resistance (h)
(A single point of incision constant tensile method)		 300
Carbon Black
Carbon Black Content(Rang) (%) 2.0~3.0
Carbon Black Dispersion Nine of 10 observation area should be grade 1 or grade 2, not more than 1 of grade3
Oxidative Induction Time (OIT)
Standard OIT (min) 100
High Pressure OIT (min) 400
85℃ Oven Ageing (Minimum Average)
90 days after baking, the standard OIT retention(%) 55
90 days after baking, the hight pressure OIT retention(%) 80
The Anti-UV Strength
Ultraviolet irradiation after 1600 hours, the standard OIT retention(%) 50
Ultraviolet irradiation after 1600 hours, the high pressure OIT retention(%) 50
-70℃ The Low Temperature Embrittlement Performance mpact Pass
Water Vapor Penetration Coefficient g.cm (cm2.s.Pa) ≤1.0X10-13
Dimensional Stability ±2



Product Specification and Technical Index (GH-1 & GB/T 17643-2011)

 Specification
Item		 0.30 0.50 0.75 1.00 1.25 1.50 2.00 2.50 3.00 Remark
Thickness (mm) 0.30 0.50 0.75 1.00 1.25 1.50 2.00 2.50 3.00
Density (g/c㎡,≥) 0.94
Tensile Yield Strength (N/mm, ≥,LD/TD) 4 7 10 13 16 20 26 33 40
Tensile Breaking Strength (N/mm, ≥,LD/TD) 6 10 15 20 25 30 40 50 60
Yield Elongation Rate (%,≥,LD/TD) - - - 11
Breaking Elongation Rate (%,≥,LD/TD) 600
Rectangular Tear Load (N,≥,LD/TD) 34 56 84 115 140 170 225 280 340
Puncture Strength (N,≥) 72 120 180 240 300 360 480 600 720
Carbon Black Content (%) 2.0~3.0
Carbon Black Dispersion Less than 1date of Grade 3 out of 10 data, grade 4,grade 5 is not allowed
